Plugins

Plugins are the primary mechanism for extending synth’s capabilities. Unlike traditional systems where functionality is hardcoded, synth’s plugin system allows for complete modularity - plugins are automatically discovered and loaded at runtime without any core modifications.

Plugin Architecture

All plugins follow a consistent architecture:

Auto-Discovery: Plugins are automatically found in the plugins/ directory
Self-Registration: Each plugin registers itself with the core system
Action-Based: Plugins provide actions that can be invoked by LLM-generated JSON
Schema-Driven: Actions are defined with clear schemas including required/optional fields
Validation: All actions are validated before execution

Available Action Plugins

Stable Plugins (in plugins/ directory):

ai_diary – Personal memory system for synth. Records conversations, thoughts, and emotions. See AI Diary Personal Memory System for details.
bio_manager – Manage persistent user biographies. Uses database settings DB_HOST, DB_USER, DB_PASS and DB_NAME.
get_logs – Return the last N lines from a log file (default: synth.log, default lines: 30). Useful to provide the LLM or operators with recent runtime output for diagnostics.
search_logs – Search logs for keywords or regular expressions (queries can be a string or list). Optional parameters: regex (bool), context (surrounding lines), lines (how many tail lines to search). Results are delivered back to the invoking interface.

Bio Manager Plugin

The bio_manager plugin provides persistent storage and retrieval of user biographical information. It automatically injects participant context into LLM prompts, including:

User profiles: Nicknames, short bio, current feelings
Chat history: Recent messages from each participant
Last accessed: Automatic timestamp updates

Database Schema:

CREATE TABLE bio (
    id VARCHAR(255) PRIMARY KEY,
    known_as TEXT DEFAULT '[]',
    likes TEXT DEFAULT '[]',
    not_likes TEXT DEFAULT '[]',
    information TEXT DEFAULT '',
    past_events TEXT DEFAULT '[]',
    feelings TEXT DEFAULT '[]',
    contacts TEXT DEFAULT '{}',
    social_accounts TEXT DEFAULT '[]',
    privacy VARCHAR(50) DEFAULT 'default',
    created_at TEXT DEFAULT '',
    last_accessed TEXT DEFAULT '',
    last_update TEXT DEFAULT '',
    update_count INT DEFAULT 0
);

Performance Optimizations:

Table Initialization Cache: Prevents repeated _ensure_table() calls that caused timeouts
Async Operations: get_static_injection() is fully async to prevent deadlock with the event loop
Connection Pool Tuning: Reduced pool size to 5 connections to ensure availability

API Methods:

get_bio_light(user_id): Retrieve lightweight bio for prompt injection
get_bio_full(user_id): Retrieve complete user profile
update_bio_fields_auto(user_id, updates): Update fields without rate limiting
get_static_injection(message, context_memory): Async method for prompt context injection

Emotion Manager Plugin

Added in version 1.0: Centralized emotional state management with decay, balancing, and persistence.

The emotion_manager plugin manages SyntH’s emotional state with sophisticated psychological modeling. It provides persistent emotional state storage, exponential decay over time, and Plutchik’s wheel-based emotion balancing for realistic emotional behavior.

Key Features:

Persistent Storage: Emotions stored in database with timestamps
Exponential Decay: Emotions naturally fade over time
Emotion Balancing: Plutchik’s wheel opposites reduce conflicting emotions
LLM Integration: Automatic emotion extraction from message tags
Global State: Readable emotional state for WebUI, animations, and plugins

Architecture:

The emotion engine consists of three main components:

EmotionState Class: Represents individual emotions with intensity and decay
EmotionManager Plugin: Core plugin handling all emotion operations
Database Layer: Persistent storage with automatic cleanup

Emotion State Model:

@dataclass
class EmotionState:
    emotion_name: str      # Emotion identifier
    intensity: float       # 0.0-10.0 scale
    timestamp: datetime    # Creation/update time

Decay Calculation:

Emotions decay exponentially over time using the formula:

\[I(t) = I_0 \cdot e^{-\frac{t}{\tau}}\]

Where: - \(I(t)\) = Current intensity - \(I_0\) = Initial intensity - \(t\) = Time elapsed (seconds) - \(\tau\) = Decay half-life (configurable, default 3600s = 1 hour)

Configuration:

EMOTION_DECAY_TAU: Decay half-life in seconds (default: 3600)
EMOTION_DECAY_THRESHOLD: Minimum intensity before removal (default: 0.1)

Plutchik’s Wheel Balancing:

The engine implements Plutchik’s circumplex model of emotion, where opposite emotions on the wheel naturally suppress each other:

PLUTCHIK_OPPOSITES = {
    'joy': 'sadness',
    'trust': 'disgust',
    'fear': 'anger',
    'anticipation': 'surprise',
    'happiness': 'sadness',
    'excitement': 'calm',
    # ... extended opposites
}

Supported Emotions:

The engine supports a comprehensive whitelist including Ekman’s basic emotions (anger, disgust, fear, happiness, sadness, surprise), Plutchik’s complex emotions (joy, trust, anticipation, etc.), and common states (anxiety, calm, confusion, etc.).

Database Schema:

CREATE TABLE emotion_state (
    id INT AUTO_INCREMENT PRIMARY KEY,
    emotion_name VARCHAR(100) NOT NULL,
    intensity FLOAT NOT NULL DEFAULT 5.0,
    timestamp DATETIME NOT NULL DEFAULT CURRENT_TIMESTAMP,
    updated_at DATETIME NOT NULL DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP,
    INDEX idx_emotion_name (emotion_name),
    INDEX idx_timestamp (timestamp)
) ENGINE=InnoDB DEFAULT CHARSET=utf8mb4 COLLATE=utf8mb4_unicode_ci;

API Actions:

static_inject: Inject current emotional state into LLM context
get_emotion_state: Get current emotional state with decay applied
update_emotion_from_tags: Extract and apply emotions from LLM message tags like {emotion intensity}
set_emotion: Set a single emotion intensity directly
decay_emotions: Apply decay to all emotions and remove low-intensity ones
sync_emotions_from_all_sources: Synchronize emotions from ai_diary, message tags, and emotion_state DB

LLM Integration:

Emotions can be specified in LLM responses using the format {emotion intensity}:

I'm so excited about this project! {excitement 8.5} {curiosity 7.2}

The engine automatically scans LLM messages for emotion tags and applies them to the emotional state with balancing.

WebUI Integration:

The emotional state is exposed to the WebUI for real-time visualization and can trigger animations and visual feedback.

Troubleshooting:

Check EMOTION_DECAY_TAU configuration for decay issues
Verify emotion names against VALID_EMOTIONS whitelist
Ensure DB credentials are configured correctly
Check that decay_emotions is called periodically

emotion_manager – Centralized emotional state management with decay and balancing.
blocklist – User blocking/unblocking functionality (no configuration).
chat_link – Cross-platform chat linking and message forwarding.
message_map – Message threading and conversation tracking.
message_plugin – Send text across registered interfaces (no configuration).
recent_chats – Access to recent conversation history.
time_plugin – Inject current time and location (no configuration).
weather_plugin – Provide weather info as static context. Optional WEATHER_FETCH_TIME sets refresh interval. Daily announcements can be enabled with WEATHER_DAILY_REPORT_ENABLED and targeted via WEATHER_DAILY_REPORT_INTERFACE (default: synth_webui). Manual reports use action trigger_weather_report with interface_id or interface_path. New endpoint available: - GET /api/weather/current — returns current plugin weather state as JSON.
tts_lipsync – (Legacy/deprecated) Generates speech audio from external HTTP TTS servers and broadcasts synth:tts-play to the WebUI. It is retained only for backward compatibility. New deployments should use the Vox subsystem and register external HTTP TTS providers via the External Endpoints UI instead. - Additional WebUI-configurable exposed variables:
- TTS_ENABLED (boolean): enable/disable the legacy plugin from the WebUI
- TTS_FALLBACK_TO_TEXT (boolean): when true, sends a text-only fallback if TTS generation fails
- Legacy compatibility: the built-in http Vox engine still supports TTS_ENDPOINTS and the same payload contract, but this is not the recommended configuration path for new installations.
vox_plugin – Vox TTS & lip-sync subsystem. Unified pipeline: text cleaning → engine generation → WAV/PCM file write → lip-sync extraction → cross-interface dispatch. Replaces tts_lipsync as the recommended TTS path. Supports pluggable engines (http, kitten); development-only stubs such as chatterbox live in plugins/_dev/vox_engines and are not imported by default. Select the active engine via ACTIVE_VOX_ENGINE (choose disabled to turn off). See Auris & Vox — Audio Subsystem.
auris_plugin – Auris STT subsystem. Unified transcription entry-point for voice notes and audio files. Supports pluggable engines; the built-in local default is vosk and external Auris providers can be added through the External Endpoints UI and mapped to auris. Select the active engine via ACTIVE_AURIS_ENGINE (choose disabled to turn off). See Auris & Vox — Audio Subsystem.

Recent Chats Plugin

Changed in version 1.0: update_chat_activity is now automatic and no longer exposed to LLM actions.

The recent_chats plugin manages conversation activity tracking and provides access to recently active chats. Unlike other plugins, this plugin focuses on mechanical operations that don’t require LLM reasoning.

Key Changes in v1.0:

Automatic Activity Tracking: Chat activity is now tracked automatically when messages are received, eliminating the need for LLM-requested update_chat_activity actions
Centralized Implementation: Activity tracking is handled in core/chat_context_manager.py instead of being duplicated across interfaces
Reduced Prompt Size: One less action for the LLM to consider

Available Actions:

get_recent_chats: Retrieve the most recently active chats
cleanup_old_chats: Remove chat records older than specified days

Database Schema:

CREATE TABLE recent_chats (
    chat_id VARCHAR(255) PRIMARY KEY,
    last_active DOUBLE NOT NULL,
    metadata TEXT,
    created_at DATETIME DEFAULT CURRENT_TIMESTAMP,
    INDEX idx_last_active (last_active)
);

Automatic Activity Tracking:

Chat activity is now tracked automatically whenever add_message_to_context() is called:

# Automatic - no LLM intervention required
asyncio.create_task(update_chat_activity(
    chat_id=extracted_chat_id,
    metadata={
        'username': sender_name,
        'user_id': sender_id,
        'interface_path': interface_path
    }
))

Benefits:

Performance: Eliminates unnecessary LLM decision-making for basic tracking
Consistency: All interfaces track activity the same way
Maintenance: Single implementation point for activity tracking logic

Development Plugins (in plugins_dev/ directory):

event – Schedule and deliver reminders. Requires DB_HOST, DB_PORT, DB_USER, DB_PASS, DB_NAME and optional CORRECTOR_RETRIES.
reddit_plugin – Submit posts and comments to Reddit. Requires REDDIT_CLIENT_ID, REDDIT_CLIENT_SECRET, REDDIT_USERNAME, REDDIT_PASSWORD and REDDIT_USER_AGENT.
selenium_elevenlabs – Generate speech audio with ElevenLabs. Set ELEVENLABS_EMAIL and ELEVENLABS_PASSWORD (synth_SELENIUM_HEADLESS controls headless mode).
selenium_ttsfree – Generate speech audio by automating https://ttsfree.com. No credentials required; set synth_SELENIUM_HEADLESS to control headless mode. Use action voice_message_ttsfree with payload: {message, language, voice, interface_path}.
- Exposed variable: Free_TTS_VOICES (mapping language -> voice definition). Configure this in the Web UI under Settings → Plugins to map language keys to voice options used by the plugin.
terminal – Run shell commands or interactive sessions. Uses TELEGRAM_TRAINER_ID to authorize access.

Terminal Plugin

The terminal plugin provides secure access to shell execution:

Single Commands: Execute one-off shell commands with output capture
Persistent Sessions: Maintain interactive shell sessions for complex workflows
Security: Limited to authorized trainer IDs only
Output Handling: Captures both stdout and stderr with proper encoding

Event Plugin

The event plugin manages scheduled reminders:

Database Storage: Events stored in MariaDB with timezone support
Background Processing: Asynchronous scheduler checks for due events
Flexible Scheduling: Support for various time formats and recurrence
Cross-Platform Delivery: Events delivered through any active interface

AI Diary Personal Memory

The ai_diary plugin implements a sophisticated personal memory system:

Record what synth says to users in conversations
Store personal thoughts about each interaction
Track emotions experienced during conversations
Build relationships and remember users over time

This creates a more human-like memory system compared to traditional technical logging. The plugin automatically injects recent diary entries into prompts, giving synth context about past conversations.

Note

For complete usage instructions and API reference, see AI Diary Personal Memory System.

The plugin requires database access and automatically creates the necessary tables on first run. In development, use recreate_diary_table.py to reset the table structure.

Plugin Registration System

Plugins are automatically discovered and loaded through the core initializer:

File Discovery: Core scans plugins/ directory recursively for *.py files
Import & Inspection: Each file is imported and checked for PLUGIN_CLASS
Instantiation: Compatible classes are instantiated (must have parameterless constructors)
Registration: Plugins register themselves with register_plugin()
Capability Reporting: Plugins provide action schemas and metadata

This design ensures that plugins are completely decoupled from the core - adding a new plugin requires only placing the file in the correct directory.

Developing Plugins

Creating a new plugin is straightforward. All plugins should extend AIPluginBase and follow these patterns:

Action Plugin

Action plugins provide executable actions that can be called via JSON. Actions are defined using a structured schema format that optimizes prompt size while maintaining full functionality.

from core.ai_plugin_base import AIPluginBase
from core.core_initializer import core_initializer, register_plugin

class MyActionPlugin(AIPluginBase):
    def __init__(self):
        # Register with the core system
        register_plugin("myplugin", self)
        core_initializer.register_plugin("myplugin")

    @staticmethod
    def get_supported_action_types() -> list[str]:
        """Return action types this plugin handles."""
        return ["my_action"]

    def get_supported_actions(self) -> dict:
        """Return schema for all supported actions using the new optimized format."""
        return {
            "my_action": {
                "schema": {
                    "type": "object",
                    "properties": {
                        "value": {
                            "type": "string",
                            "description": "The value to process"
                        },
                        "option": {
                            "type": "boolean",
                            "description": "Optional flag"
                        }
                    },
                    "required": ["value"]
                },
                "brief": "Execute my custom action with a value",
                "examples": {
                    "description": "Execute my custom action with a value. The option flag controls additional behavior.",
                    "instructions": {
                        "when_to_use": "Use this action when you need to process a value with optional configuration",
                        "common_pitfalls": ["Ensure value is not empty", "Boolean option defaults to false"]
                    },
                    "examples": [
                        {
                            "scenario": "Basic value processing",
                            "payload": {"value": "hello world"}
                        },
                        {
                            "scenario": "Processing with option enabled",
                            "payload": {"value": "hello world", "option": true}
                        }
                    ]
                }
            }
        }

    def validate_payload(self, action_type: str, payload: dict) -> list[str]:
        """Validate action payload before execution."""
        errors = []
        if action_type == "my_action" and "value" not in payload:
            errors.append("payload.value is required")
        return errors

    async def handle_custom_action(self, action_type: str, payload: dict):
        """Execute the action logic."""
        if action_type == "my_action":
            # Perform your action here
            result = process_value(payload["value"])
            return result

# Required: Export the plugin class
PLUGIN_CLASS = MyActionPlugin

Action Schema Format

Added in version 1.0: New optimized action schema format for reduced prompt sizes.

Actions are defined using a structured three-tier format that optimizes LLM prompt size while maintaining full functionality:

Schema Tier (JSON Schema): Defines the structure, field types, and required fields. Used for validation and LLM prompt generation.
Brief Tier (One-line description): Concise description of what the action does. Included in LLM prompts for context.
Examples Tier (Detailed documentation): Comprehensive descriptions, usage instructions, and examples. Used only by the corrector when LLM makes mistakes.

{
    "my_action": {
        "schema": {
            "type": "object",
            "properties": {
                "field_name": {
                    "type": "string",  # or "number", "boolean", "array", "object"
                    "description": "What this field does",
                    "enum": ["option1", "option2"]  # optional: restrict to specific values
                }
            },
            "required": ["field_name"]  # array of required field names
        },
        "brief": "One-line description of what the action does",
        "examples": {
            "description": "Detailed description with usage context and edge cases",
            "instructions": {
                "when_to_use": "When to use this action",
                "common_pitfalls": ["Common mistakes to avoid"],
                "notes": ["Additional important information"]
            },
            "examples": [
                {
                    "scenario": "Description of use case",
                    "payload": {"field_name": "example_value"}
                }
            ]
        }
    }
}

Field Types Supported:

"string" - Text values
"number" - Numeric values (integers/floats)
"boolean" - True/false values
"array" - Lists of values
"object" - Nested objects

Schema Validation:

The schema follows JSON Schema standards and is automatically validated. Use enum to restrict values to specific options:

"priority": {
    "type": "string",
    "enum": ["low", "medium", "high"],
    "description": "Message priority level"
}

Backward Compatibility:

The old format (description, required_fields, optional_fields) is automatically converted to the new format. Existing plugins continue to work without changes.

Plugin Flow

The plugin system integrates seamlessly with the message chain:

digraph plugin_flow { rankdir=LR; node [shape=box, style=rounded]; A [label="1. Plugin auto-discovered\nand instantiated"]; B [label="2. Plugin registers actions\n→ available_actions"]; C [label="3. Plugin provides instructions\n→ action_instructions"]; D [label="4. LLM generates JSON\naction request"]; E [label="5. Action parser routes\nto plugin"]; F [label="6. Plugin executes logic\nand returns result"]; A -> B -> C -> D -> E -> F; }

Step-by-step integration:

Auto-Discovery: Core initializer finds and loads plugin from filesystem
Registration: Plugin registers its supported actions with the system
Instruction Provision: Plugin provides usage instructions for LLM integration
Action Generation: LLM creates JSON actions based on available capabilities
Routing: Action parser matches actions to appropriate plugin handlers
Execution: Plugin performs the requested operation and returns results

Best Practices

Action Schema Design: Use the new three-tier action format for optimal prompt efficiency. Keep brief descriptions under 100 characters.
Schema Validation: Define comprehensive JSON schemas with proper types and constraints. Use enum for restricted values.
Brief Descriptions: Write concise, actionable descriptions for the brief field. Focus on what the action does, not how.
Examples Documentation: Provide comprehensive examples in the examples tier. Include common use cases, edge cases, and error scenarios.
Security First: Always validate inputs and restrict access to authorized users only.
Error Handling: Provide meaningful error messages and handle edge cases gracefully.
Documentation: Include clear descriptions and examples in the examples tier for corrector assistance.
Testing: Test plugins independently before integration with the full system.
Performance: Consider async operations for I/O-bound tasks to maintain responsiveness.

For examples, examine existing plugins like plugins/ai_diary.py (new format) or plugins/terminal.py (legacy format) in the repository.
