Architecture Overview

The Synthetic Heart is a highly modular AI persona system designed for extensibility and flexibility. The architecture separates concerns into distinct layers, allowing independent development and swapping of components without modifying the core system.

Core Principles

Modularity and Extensibility

Components (Cortex engines, plugins, and interfaces) are not hardcoded in the core. Instead, they are dynamically discovered and loaded at runtime through auto-registration mechanisms. This ensures that new functionality can be added by simply placing compatible modules in the appropriate directories.

Message-Driven Architecture

All interactions flow through a centralized message chain that handles JSON action parsing, validation, and execution. Components communicate through well-defined interfaces rather than direct coupling.

Registry-Based Component Management

Components register themselves with central registries, providing metadata about their capabilities. The core system then orchestrates interactions based on this self-reported information.

System Components

core

The foundational layer containing:

• Message Chain (message_chain.py): Central orchestrator for incoming messages, JSON extraction, and action execution flow.

• Action Parser (action_parser.py): Executes validated actions from parsed JSON, routing them to appropriate component handlers.

• Core Initializer (core_initializer.py): Auto-discovers and loads all components from plugins/, cortex/, and interface/ directories.

• Registries: Centralized management for Cortex engines, interfaces, plugins, and validation rules.

• Transport Layer: Handles communication between components and interfaces.

• Interface Path System: Unified hierarchical addressing system using interface_path format (e.g., “telegram_bot/chat_id/thread_id”) for consistent conversation identification across all platforms. See Interface Path System for detailed documentation.

interface

Chat platform integrations (Telegram, Discord, Reddit, etc.). Each interface:

• Inherits from AIPluginBase or implements compatible interfaces

• Registers supported actions (e.g., sending messages, media)

• Handles platform-specific message formatting and rate limiting

• Provides trainer ID validation for security

cortex/

Runtime engine implementations (OpenAI, Google Gemini, manual input, etc.). Each engine:

• Extends AIPluginBase for consistent interface

• Handles prompt construction and response generation

• Manages model-specific limits and capabilities

• Supports both text and multimodal interactions

Cortex engines expose configuration variables (API keys, endpoints, model selectors) through the shared settings registry. These variables can be edited in the Web UI even when the engine is not active. When a required variable is missing, the engine may load in a degraded state and is surfaced as failed in the Components view so operators can see it needs attention. Variables marked with needs_component_reload automatically trigger a reload of the owning Cortex engine after an update, allowing API keys to be applied without restarting the whole system.

Prompt Assembly

Prompt assembly is now centered on the typed core.prompt_request.PromptRequest model.

• core.prompt_engine.build_prompt_request() is the canonical builder.

• build_json_prompt() remains as a deprecated alias for compatibility.

• The builder still returns a compatibility dict for older callers, but it now

  attaches the typed request under __prompt_request.

• Migrated engines render the typed request natively through

  core.prompt_renderers instead of serializing the full prompt as one indented JSON blob.

This split lets the runtime preserve conversation turns, keep system instructions stable for caching, and handle chat, grillo, delivery, and live prompt modes without forcing every engine down the same text-only path.

plugins

Action providers that extend synth’s capabilities (terminal access, weather, file operations, etc.). Each plugin:

• Implements action schemas with required/optional fields

• Provides prompt instructions for LLM integration

• Handles validation and execution of specific actions

• Can be pure action providers or full AI plugins

Advanced Components

Event Handler

Allows the synth to schedule and manage events for future execution. Events can be spontaneous or user-requested, enabling proactive behaviors like sending morning greetings, weather warnings, or checking in on users. This creates a sense of initiative and care.

Thinking Engine (G.R.I.L.L.O.)

A low-priority, configurable background process that generates internal thoughts and proposals for the synth. It picks up on conversations or ideas, prompting autonomous actions. For example, if users discuss AI art limitations, the synth might research human art concepts or artist communities. This demonstrates emerging “will” and self-directed behavior, though full implementation depends on available plugins like web search.

Message Flow

The following diagram shows the complete message processing pipeline:

digraph message_flow { rankdir=TB; node [shape=box, style=rounded]; User [label="User Message"]; Interface [label="Interface\n(Telegram/Discord/etc.)"]; MessageChain [label="Message Chain"]; JSONExtract [label="JSON Extraction"]; ActionParser [label="Action Parser"]; Component [label="Component\n(Plugin/Cortex)"]; Response [label="Response"]; User -> Interface; Interface -> MessageChain; MessageChain -> JSONExtract; JSONExtract -> ActionParser [label="Valid JSON"]; JSONExtract -> Corrector [label="Invalid JSON"]; Corrector -> MessageChain [label="Retry"]; ActionParser -> Component; Component -> Response; Response -> Interface; Response -> User; Corrector [label="Corrector Middleware\n(LLM-assisted)"]; }

Message Queue System

The Synthetic Heart uses an asyncio.PriorityQueue for processing messages in the correct order. Messages are prioritized to ensure high-priority events (like scheduled messages) are processed before regular chat messages.

Priority Levels: - HIGH_PRIORITY (0): Scheduled events, urgent notifications - NORMAL_PRIORITY (1): Regular chat messages

PriorityQueue Fix: To prevent TypeError when comparing messages with identical priorities, the queue uses a monotonic counter as tiebreaker. Each message is stored as (priority, counter, item) instead of (priority, item), ensuring consistent ordering even when priorities are equal.

Consumer Loop: A dedicated async task continuously processes queued messages, ensuring no message loss and proper serialization of operations.

Database Connection Pool

The system maintains a single aiomysql connection pool with carefully tuned parameters:

• Max Size: 5 connections (reduced from 8 to prevent bio_manager timeouts)

• Min Size: 1 connection (keeps one connection alive)

• Timeout: 10 seconds for connection acquisition

Bio Manager Optimization: The bio_manager plugin caches table initialization and uses async database operations to prevent TimeoutError when retrieving user profiles during prompt injection.

Recent Fixes

PriorityQueue TypeError Fix (November 2025):

The message queue was experiencing TypeError: '<' not supported between instances of 'dict' and 'dict' when processing messages with identical priorities.

Root Cause: Python’s heapq compares tuple elements when priorities are equal, but dict objects cannot be compared with <.

Solution: Added monotonic counter as tiebreaker in queue tuples: .. code-block:: python

# Before: (priority, item) - fails when priority equal # After: (priority, counter, item) - always comparable

_counter += 1 await _queue.put((priority, _counter, item))

Files Modified: - core/message_queue.py: Added global counter and updated all put() calls

Impact: Eliminates queue crashes and ensures consistent message processing order.

Detailed Flow:

1. Message Reception: Interface receives message from user and forwards to message chain

2. JSON Detection: Message chain attempts to extract JSON actions from the text

3. Validation & Correction: If JSON is invalid, corrector middleware queries the active Cortex engine to fix it

4. Action Execution: Validated actions are parsed and routed to appropriate components

5. Response Generation: Components execute actions and generate responses

6. Output Delivery: Responses are sent back through the originating interface

Component Auto-Discovery

Components are automatically discovered through a recursive import system:

• The core initializer scans plugins/, cortex/, and interface/ directories

• Each Python file is imported and checked for a PLUGIN_CLASS attribute

• Compatible classes are instantiated and registered with appropriate registries

• Components self-report their capabilities through standardized methods

• No manual registration or configuration files required

This approach ensures that adding new functionality requires only: 1. Creating a compatible class in the appropriate directory 2. Implementing required interface methods 3. Restarting the application

Security and Validation

• Trainer ID Validation: Interfaces validate that commands come from authorized trainers

• Action Validation: All actions are validated against component schemas before execution

• Rate Limiting: Built-in rate limiting prevents abuse across all components

• Error Handling: Comprehensive error handling with user-friendly notifications

The architecture’s modular design ensures that security policies can be consistently applied across all components without code duplication.

Unified Lane & Unified History

Synthetic Heart supports optional Unified Lane and Unified History behaviors to improve continuity across interfaces and sessions.

Unified Lane (Context Linking)

Allows multiple interface paths to map to a single shared context lane. This is useful when you want WebUI, Discord, and other interfaces to share a common conversation history.

Configure the mapping via CONTEXT_LINK_MAP (JSON), for example:

{
  "synth_webui/SESSION_UUID": "lane_Trainer_Main",
  "discord_bot/123456/0": "lane_Trainer_Main",
  "123456": "lane_Trainer_Main"
}

By default the WebUI uses a single persistent session id that is stored in backups/webui_session_id.txt. This ensures history and window state survive container restarts. An advanced, experimental option MULTI_SESSION can be toggled to true; when enabled each browser connection gets its own independent session. This mode is unstable and should only be used for testing.

The resolver checks for exact path matches first and then tries a user-id match using the second path segment (interface/chat_id/...).

Unified History

When UNIFIED_HISTORY is enabled, the current chat history is built by merging global DB history with in-memory chat logs across all interfaces. This creates a shared “brain” for the synth. Disable this flag if you need strict isolation between users or channels.

Changed in version 1.0: Unified history entries coming from other chats are now prefixed with [from <interface_path>] to make it explicit they are not part of the current conversation.
